| Parameter | Value |
|---|---|
| Rated Voltage (Un) | 0.65–3.6 kV |
| Reactive Power (Qn) | 750–9000 kvar |
| Frequency (Fn) | 0.3–50 kHz |
| Rated Current (In) | ≤ 2500 A |
| Cooling Method | Water cooled (single circuit) |
| Standards | GB/T 3984 · IEC 60110 |
| № | TYPE | Un (V) | Qn (kVAR) | Fn (Hz) | In (A) | Cn (μF) | L (mm) | W (mm) | H (mm) | GROUPS | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | RAM0.65-750-1S | 650 | 750 | 1000 | 1154 | 282.52 | 343 | 142 | 335 | 5 | Enquire |
| 2 | RAM0.75-1000-0.3S | 750 | 1000 | 300 | 1333 | 943.14 | 343 | 205 | 545 | 6 | Enquire |
| 3 | RAM1.0-2000-1S | 1000 | 2000 | 1000 | 2000 | 318.31 | 343 | 175 | 360 | 8 | Enquire |
| 4 | RAM1.0-2400-50S | 1000 | 2400 | 50000 | 2400 | 7.64 | 350 | 142 | 300 | 10 | Enquire |
| 5 | RAM1.2-1000-0.5S | 1200 | 1000 | 500 | 833 | 221.05 | 343 | 175 | 360 | 4 | Enquire |
| 6 | RAM1.25-1200-1.2S | 1250 | 1200 | 1200 | 960 | 101.86 | 343 | 127 | 330 | 6 | Enquire |
| 7 | RAM1.5-2666-0.6S | 1500 | 2666 | 600 | 1777 | 314.3 | 343 | 175 | 545 | 8 | Enquire |
| 8 | RAM1.5-3500-1S | 1500 | 3500 | 1000 | 2333 | 247.57 | 343 | 175 | 545 | 8 | Enquire |
| 9 | RAM1.8-3000-1S | 1800 | 3000 | 1000 | 1667 | 147.37 | 343 | 175 | 330 | 8 | Enquire |
| 10 | RAM2.0-2000-0.5S | 2000 | 2000 | 500 | 1000 | 159.15 | 343 | 175 | 400 | 8 | Enquire |
| 11 | RAM2.0-4000-2S | 2000 | 4000 | 2000 | 2000 | 79.58 | 343 | 150 | 435 | 8 | Enquire |
| 12 | RAM2.0-2000-2.5S | 2000 | 2000 | 2500 | 1000 | 31.83 | 343 | 150 | 220 | 4 | Enquire |
| 13 | RAM2.0-3000-2.5S | 2000 | 3000 | 2500 | 1500 | 47.75 | 343 | 150 | 270 | 6 | Enquire |
| 14 | RAM2.5-6000-2.5S | 2500 | 6000 | 2500 | 2400 | 61.12 | 343 | 150 | 490 | 8 | Enquire |
| 15 | RAM2.5-6000-3S | 2500 | 6000 | 3000 | 2400 | 50.93 | 343 | 150 | 490 | 8 | Enquire |
| 16 | RAM3.0-2500-1S | 3000 | 2500 | 1000 | 833 | 44.21 | 343 | 150 | 270 | 4 | Enquire |
| 17 | RAM3.2-4500-0.8S | 3200 | 4500 | 800 | 1406 | 87.43 | 440 | 165 | 550 | 6 | Enquire |
| 18 | RAM3.2-4000-1.5S | 3200 | 4000 | 1500 | 1250 | 41.45 | 343 | 175 | 360 | 6 | Enquire |
| 19 | RAM3.2-4500-1.5S | 3200 | 4500 | 1500 | 1406 | 46.63 | 390 | 165 | 500 | 10 | Enquire |
| 20 | RAM3.6-9000-1S | 3600 | 9000 | 1000 | 2500 | 110.52 | 559 | 170 | 600 | 8 | Enquire |
Talk to our engineers about custom specifications or to request a datasheet.
